Single Swing Posi-Stop
SW-01-D — $99.00
Specifications
| DESCRIPTION | DIMENSIONS (in.) |
| Minimum Spacing Between Two Impact Plates | 1.24 |
| Maximum Impact (Swing) Plate Protrusion | 0.50 |
| Body (Frame) L x W x H | 1.24 x 1.23 x 2.12 |
| Overall on Guide Rail W x H | 2.00 x 2.25 |
| S/S Thumb Screw Thread Size x Length | 10-24 x 0.69 |
| S/S Thumb Screw Head DIA x Height | 0.25 x 0.25 |
| Impact Plate Overall L x W x Thickness | 1.00 x 1.62 x 0.25 |
| Lock Plate Overall L x H x Thickness | 1.22 x 0.75 x 0.75 |
| Socket Head Lock Screw (Thread Size x Length) | 1/4 – 20 x 1.25 |
| Unit Weight | 0.40 lbs. |
Features
- Impact plate protrusion is controlled with stainless steel thumb screw or (optional) with set screw and hex driver.
- Swing Stop is locked in place with two socket head screws and dual hole lock plate providing high locking capacity.
- Gravity action of the swing (impact) plate is supported by compression spring with low (.20 lbs) retraction force.
- Impact plate can be pulled from the body (for cleaning) without removing it from the Guide Rail.
- Stop can be positioned at desired location by aligning the graduation lines on the tape with L/H or R/H top edge of the block.
- Stop body is machined from 6061-T6 anodized aluminum, impact plates are machined from 304 stainless steel and lock plates are machined from 01 tool steel.
- Minimum workpiece thickness is 3/8″.
